主 机：长1200*宽1000*高2100mm
纱管规格：a04 φ47*139mm
拨盘转速：300rpm
机器功率：0.55kw
braider：1200*1000*2100
bobbin：a04 φ47*139mm
horngear：300rpm
motor：0.55kw
spool size: 300*130mm
该系列针对钓鱼线、医疗等行业设计制造，断线断丝自动停车，功能齐全。编织过程中不甩油。24小时运转，最长7天可不用停机换材料。
this series braiding machinery is desinged for production of fishing line, suture, jacquared,and other thin line or thread. it has auto-stop motion, and can adopt top take-up system to collect the final products(optional). the machines can running for 24hours x 7days without change bobbins(depends on yarn size)
细线类编织机主要用于生产钓鱼线、手术缝合线、电脑提花龙头通丝、手机挂绳、耳机线、球拍绳、首饰绳、牙线等。
widely used for: fishing line, suture line, jacquard harnesscords, mobile phone lanyard, earphone cable, racket line, fashion accessories rope, dental floss
涤纶、丙纶、pe、hdpe、尼龙、大力马线、棉、高分子材料等其他复合材料。
polyester, pp, pe, hdpe, nylon, dyneema, high polymer material, cotton composite material, etc.
